Description
The TL-SG108E 8-port gigabit easy smart switch is an ideal upgrade from an unmanaged switch, designed for small and medium business networks that require simple network management. Network administrators can effectively monitor traffic via port mirroring, loop prevention and cable diagnostics features. To optimize traffic on your business network, TL-SG108E offers both port and tag based QoS to keep latency-sensitive traffic moving smoothly and jitter-free. Additionally, port-based, tag-based and MTU VLAN can improve security and meet more network segmentation requirements. Moreover, with its innovative energy-efficient technology, the TL-SG108E can save up to 80% of power consumption, making it an eco-friendly solution for your business network.
| Switch-Typ |
Unmanaged |
| Switch-Ebene |
L2 |
| Quality of Service (QoS) Support |
Ja |
| Web-basiertes Management |
Ja |
| Anzahl der basisschaltenden RJ-45 Ethernet Ports |
8 |
| Basic Switching RJ-45 Ethernet Ports-Typ |
Gigabit Ethernet (10/100/1000) |
| Netzstandard |
IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.3, IEEE 802.3u, IEEE 802.3x |
| Port-Spiegelung |
Ja |
| Link Aggregation |
Ja |
| Broadcast-Sturmkontrolle |
Ja |
| Ratenbeschränkung |
Ja |
| Auto MDI/MDI-X |
Ja |
| Auto-Negotiation-Funktion |
Ja |
| VLAN-Unterstützung |
Ja |
| Anzahl der VLANs |
32 |
| MAC-Adressentabelle |
4000 Eintragungen |
| Routing-/Switching-Kapazität |
16 Gbit/s |
| Durchgang |
11,9 Mpps |
| Store-and-Forward |
Ja |
| Anzahl Queues |
4 |
| Jumbo Frames Unterstützung |
Ja |
| Jumbo-Frames |
16000 |
| Datenpaket-Pufferspeicher |
1,5 MB |
| IGMP snooping |
Ja |
| Anzahl der gefilterten Multicast-Gruppen |
128 |
| Produktfarbe |
Schwarz |
| Gehäusematerial |
Metall |
| LED-Anzeigen |
Ja |
| Zertifizierung |
FCC, CE, RoHS |
| Netzteil enthalten |
Ja |
| AC Eingangsspannung |
100 – 240 V |
| AC Eingangsfrequenz |
50/60 Hz |
| DC input Spannung |
9 V |
| Eingangsstrom |
0.6 A |
| Power over Ethernet (PoE) |
Nein |
| Betriebstemperatur |
0 – 40 °C |
| Temperaturbereich bei Lagerung |
40 – 70 °C |
| Relative Luftfeuchtigkeit in Betrieb |
10 – 90% |
| Luftfeuchtigkeit bei Lagerung |
5 – 90% |
| Wärmeableitung |
12,55 BTU/h |
| Breite |
158 mm |
| Tiefe |
101 mm |
| Höhe |
25 mm |
| Mitgelieferte Kabel |
AC |
| Benutzerhandbuch |
Ja |
| Verpackungsart |
Box |
| Warentarifnummer (HS) |
85176990 |
|
